1000BPH Gallon Water Filling Plant For 20L Barrel Water Line

Name: 1000BPH Gallon Water Filling Plant For 20L Barrel Water Line
Brand: FILL PACK
Price: 38 USD

Brand Name : FILL PACK

Model Number : QGF-1000

Certification : CE, ISO9001

Place of Origin : ZhangJiaGang JiangSu China

MOQ : 1 set/pcs

Price : USD$38,000.00-USD$43,000.00

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5 sets/month

Delivery Time : 30-35days

Packaging Details : Wooden case pacakge

Bottle size : 3-5 gallon bottle

Capacity : 1000BPH

Material : SUS 304

Automatic grade : Automatic

Keyword : bottled water making machine

Control : PLC+Touch Screen

Capping Type : sealing

Video outgoing-inspection : Provided

Contact Now

3 / 5 gallon / 20L bottle water washing filling capping equipment / plant / machine / system / line

This gallon filler specially produces 3&5 gallons barreled drinking water. This series gallon filler integrates bottle washer, filler and sealer into one unit.

Items	Name of machine	Model	Size(mm)	Qty.
1200BPH gallon water filler
1	Automatic de-capper	BG-3	12008001950	1set
2	Rotary external washer	XT-3	180015501750	1set
3	Monoblock jar rinser	CXJ-3	600021002100	1set
3.1	Automatic jar loading-unloading device	ST-6	/	1set
4	Automatic rotary jar filler	TG-12	300022002500	1set
4.1	Automatic belt capper	LDYG-1	600200300	1set
4.2	Automatic cap lifter-washer	SG-1	8008003000	1set
5	Steam shrink tunnel	SB-1000	10004501500	1set
6	Light checker	DJ-1	800200300	1pc
7	Belt conveyor system	SYS-1	35m	1set
8	Ink jet code printer	PM-368	347220100	1set
OPTION
8	Automatic neck labeling machine	TB-50	10008002000	1set
8.1	Steam shrink tunnel	SB-1000	10004501500	1set
8.2	Steam generator	9KW	6305601360	1set
9	Automatic stacker	543	270020002000	1set

Details of main machines

1000BPH Gallon Water Filling Plant For 20L Barrel Water Line

Automatic de-capper

 This machine is driven by cylinder, controlled by PLC; Automatic working by barrel checking;
 De-capping head is composed by claw device and cylinder, de-capping head position can move up and down, claw device can be adjusted slightly to be suitable for different caps.

Automatic rotary jar filler

Bottle fed by a star wheel into the bottle filling machine, filling area to reach the starting point, the roller bottles along the cam will hold up, start filling valve for filling a bottle, and with the body, etc. together synchronously rotating; bottles arrive irrigation end point loading zone, to reach the cam roller bottles with low self-reset Close filling valve, filling the end of the barrel with the star wheel sent out of the bottle filling machine.

Automatic neck labeling machine

Adopting model group design, module controlled; Achieve veracity and fast sleeving.
 With the good quality touching operation screen, achieving operation by finger, easy and shortcut.
 It is a high automatic packing machine. Just one person handles, easy operation.
 Higher safely and stability for operation and saving time of manpower.

Steam shrink Machine

Whole SUS304 construction, including electrical boiler to generate steam and shrink tunnel especially for barrel cap film;

 Power: 20KW
 Dimension: 1000*600*1200mm
 Weight: 100kg
